Capacity : 110–1,500 L
Temperature Range: -40°C to +85°C (±1°C stability).
Salt Spray (NSS/AASS/CASS): 5% NaCl solution, pH 4.0–7.2
Cyclic Conditions: 45~96%RH
Cycle Customization: 1–99 hrs
Spray System: 1.0–2.0 mL/hr per 80 cm²
Specifications
| Serial number | Capacity ( m3 ) | 0.11 | 0.27 | 0.50 | 0.80 | 1.50 | |
| 1 | Model | Salt Spray Chamber | SSTC-60 | SSTC-90 | SSTC-120 | SSTC-160 | SSTC-200 |
| 2 | Internal Dimension WxHxD (mm) | 600x400x450 | 900x500x600 | 1200x500x800 | 1600x500x800 | 2000x500x800 | |
| 3 | External Dimension WxHxD (mm) | 1100x960x760 | 1400x1200x900 | 1900x1300x1400 | 2150x1350x1400 | 2700x1500x1700 | |
| Lab Temperature | Saline test (NSS ACSS) 35 ± 1℃; Corrosion Test (CASS) 50 ± 1℃ | ||||||
| 4 | Pressure Bucket Temperature | Saline test (NSS ACSS) 47 ± 1℃; Corrosion Test (CASS) 63 ± 1℃ | |||||
| 5 | Saline Capacity(L) | 15 | 25 | 40 | 40 | 40 | |
| 6 | Saline Concentration | 5% concentration of NaCI, or every Liter 5% NaCI add 0.26g CuCI2H20 | |||||
| Compressed Air Pressure(Kgf) | 1.0 ~ 6.0 | ||||||
| 7 | Spray Volume | 1.0~2.0ml/ 80cm²/h (working at least 16 hours, and take the average value) | |||||
| 8 | Spray Form | Continuous spraying or programmable spraying | |||||
| 9 | Power | AC 220V; 1phase 3 lines 50/60Hz | |||||
| Weight (Kg) | 65 | 80 | 120 | 160 | 200 | ||
| 10 | Note：SOther studio sizes or special features: Customizable as per requirements; The main parameters and configurations can be obtained separately from our sales engineers | ||||||
